Have a particular specification you're looking to compare apples to apples? We get it. No need to stress about calling and asking for specifics, we put everything out there so you can be educated when you go to pick up your new utv wheels, tires, or accessories.

Product Specs

UTV Wheels:

STYLE SIZE OFFSET LBS BACKSPACE MAX LOAD
V01 14x7 +15mm 11.90 4.59 1000
V01 15x7 +15mm 13.23 4.59 1000
V02 14x7 +20mm 13.45 4.79 1000
V02 15x7 +20mm 14.77 4.79 1000
V03 14x7 +25mm 12.02 4.98 1000
V03 14x7 -32mm 12.46 2.74 1000
V03 15x7 +25mm 13.45 4.98 1000
V03 15x10 +0mm 14.60 5.00 1000
V04 14x7 +15mm 13.23 4.59 1000
V04 15x7 +15mm 14.33 4.59 1000
V05 14x7 +35mm 13.83 5.38 1000
V05 15x7 +35mm 14.82 5.38 1000
V06 15x8 +40mm 16.72 6.07 1350
V07 15x7 +25mm 16.50 4.98 1250
V08 15x7 +30mm 16.86 5.18 1250
V09 15x7 +40mm 16.96 5.57 1600
V09 15x10 +0mm 19.90 5.50 1600
V09 17x8 +40mm 20.40 6.07 1600
V13 15x7 +10mm 17.20 4.39 1400
V14 14x7 +20mm 11.10 4.79 1400
V14 15x7 +20mm 13.10 4.79 1400
V15 15x7 +45mm 17.50 5.77 1400




UTV Accessories:

Hardware Kit Fits: All Beadlock Wheels
VBR10 Beadlock Ring Fits: All Beadlock Wheels
VBR20 Beadlock Ring Fits: All Beadlock Wheels
VBR30 Beadlock Ring Fits: All Beadlock Wheels
Fits: V01-V08
VCAP1 Cap Black Out Fits: V01-V08
VCAP2 Cap Fits: V09, V14, V15
VCAP1 Logo Kit Fits: V01-V08
VCAP2 Logo Kit Fits: V09, V14, V15


UTV Tires:

SIZE WIDTH WHEEL RADIAL
PLY
 Duro
Alpha 30x9.50R14 9.50 14 Yes 8 65A
Alpha 32x10.00R15 10.00 15 Yes 8 65A
10.00 15 Yes 8 55A/65A
Tango
 TBA TBA TBA TBA TBA

ENGINEERING

All Valor Offroad Wheels utilize high quality A356.2 aluminum with T6 heat treatment during the Low Pressure Casting process. There are varieties of casting processes, click here to learn more about why Low Pressure Casting is our preferred manufacturing technique.

All Valor Offroad beadlock rings are manufactured using billet 6062 with T6 heat treatment.

TESTING

The safety testing spec we adhere to is SAE J2530. This is a standard automotive grade testing that meets or exceeds all OEM engineering and manufacturing standards to keep you and your passengers safe.

All of our products are additionally tested in some of our favorite proving grounds: The Rocky Mountains of Colorado, The stunning terrain of Sand Hollow Utah, and the pristine deserts of Northern Arizona.

FINISHES

All wheels undergo three surface treatments to remove any imperfections and allow a complete dry out. Next, the powder premium paint finish is applied and then a thick coat of wet clear coating.

After wheels are cured, the finish endures a brutal 470 hour spray test (industry average is 240 hours) to ensure a lifetime of use in mother nature's harshest conditions.
